EPD-IES-0004708:002 (S-P-04708)

Trocellen Class

TROCELLEN CLASS is the brand name for CE marked & Euroclass product portfolio of Trocellen. CE marking guarantees safe products within Europe, resulting in a high degree of legal certainty in the planning process. Moreover, CE marking means safety, as all products were checked by indipendent bodies.

The product range is based on closed cell, chemically cross-linked, polyolefin resin foam products, offering high performance in terms of flame retardant protection in the event of fire, plus extremely long-lasting thermal insulation performance and soundproofing.

TROCELLEN CLASS is suitable for the insulation of air ducts, guaranteeing long-lasting and effective thermal insulation inorder to avoid heat loss and consequently save costs. It is easily applied through pre-adhesion process. The right thickness needs to be calculated according to the necessary thermal insulation: Trocellen has developed a specific software (acc. to ISO 12241) in order to determine the thickness and the energy saving during the use stage of the product (https://insulation.trocellen.com/tools/use-trocellen-calculation-software-free/ )

Main Advantages:

· Excellent condensation barrier ability

· Excellent μ-value - from 1000 to 15000

· Costant and long lasting λ

· Fire resistant, flammability classification can be B-s2,d0, no dripping.

· Ultra low smoke toxicity and opacity (F1 classification according to NF 16-101)

· Safe, non-toxic, non-allergen, mould resistant (VDI 6022-1 certified)

· Very low VOC emission: A+ classification according to French systems (tested according ISO 16000)

Trocellen products have showed a service life of more than 23 years on site, with the same performance and no damage. The thermal conductivity was measured and resulted with same values as measuredjust after being manufactures. This demonstrates the long-lasting life ofTrocellen products.

Registration numberEPD-IES-0004708:002 (S-P-04708)
PCR2019:14 Construction products (EN 15804+A2) 1.3.4
c-PCR2019:14-c-PCR-005 Thermal insulation products (EN 16783) (c-PCR to PCR 2019:14) 1.0.0
StatusValid
Publication date2022-03-03
Valid until2027-03-03
EN 15804 compliantYes
Geographical scopeGlobal
