EPD-IES-0008397:005 (S-P-08397)

Hinges CHIC

CHIC HINGE

Set of hinges (top and bottom) for side-hung or secondary sash with tilt-and-turn CHIC.

Sash opening to 180°.

Maximum load capacity up to 150 kg.

Available in right- and left-hand versions.

Assembly is simple, fast and easy using the special pre-assembled cams.

When there is an additional fastening mechanism, you need to use the CHIC fastening element.

Both hinges are adjustable (3D).

CHIC - T/T KIT ARM

Set of hinges (top and bottom), completely pre-assembled and ready to be installed on the profile.

They enable tilt-and-turn opening combined with the mechanisms.

Available in right- and left-hand versions.

Micro-ventilation and logica versions.

The arm is equipped with micro-ventilation as standard (adjustable).

Moving the fastening pawl takes the arm from conventional to logica.

Registration numberEPD-IES-0008397:005 (S-P-08397)
PCR2019:14 Construction products (EN 15804+A2) 1.3.4
StatusValid
Publication date2023-04-07
Valid until2028-04-05
EN 15804 compliantYes
Geographical scopeEurope
LCA PractitionerValerio Venturi
