Technishield 110 Glazed Partitions

Technishield is a range of external steel-framed door and partition systems, supplied either single-glazed or double-glazed, and available in 304 and/or 316 stainless steel or powder-coated mild steel variants.

TECHNISHIELD 110 GLAZED PARTITIONS

Single glazed Technishield 110 is a stylish and robust glazing system with fire resistance of up to 120 minutes in terms of both Integrity and insulation. Formed from mild steel framing sections, incorporating thermally resistant materials, the system is supplied with a high quality powder coat finish. The screen would normally be glazed with a 52mm intumescent glass but can also accommodate thicker double glazed units where greater acoustic performance is required.

Screens can incorporate intermediate mullions and transoms and can be supplied up to 3380mm high with unlimited width. It is also possible to incorporate butt-jointed glazing with the addition of Shoreditch features, if required. There is no option to include doors in the Technishield 110 system.

This EPD applies to OPL's Technishield 110 EI120 partitions, glazed with 52mm glass.
