Aluminium Framed Double Glazed Doors

EDGE SERIES

The Edge series features two striking aluminium-framed double-glazed doors, the Edge Symmetry and Edge Affinity (along with a flush frameless double-glazed door leaf, the Edge Flush).

EDGE SYMMETRY

The double-glazed Edge Symmetry is a hugely popular glass door offering excellent acoustic performance. This elegant door is designed for use within our Microflush door frame and can be hinged or pivoted. The Edge Symmetry door features a slim 30mm standard width stile at the leading edge; 18mm visible on the corridor side when the door is in a closed position. If a lock is required it can be a dead lock, sash lock or latch. Single or paired doors are available, and the maximum door height is 3000mm.

The double-glazed Edge Symmetry door uses toughened glass throughout: 6mm inside and 8mm outside.

EDGE AFFINITY

The double-glazed Edge Affinity door is an aluminium-framed glass door which offer outstanding acoustic performance. The door features a 78mm wide stile at the leading edge; 66mm visible on the corridor side when the door is in a closed position. The stile can accommodate a dead lock, sash lock or latch. Single or paired doors are available, and the maximum door height is 3000mm.

The double-glazed Edge Affinity door uses 6mm-toughened glass inside and up to 8.8mm-annealed acoustic laminated glass outside.

ELITE SERIES

The Elite series, featuring Elite Symmetry and Elite Affinity, is our striking range of aluminium-framed double-glazed acoustic doors. These 100mm-thick glass doors have been designed exclusively for use within our Revolution 100 double-glazed system.

The Elite doors are double-rebated and incorporate numerous acoustic seals, including two drop seals, in order to achieve impressive acoustic performance.

ELITE SYMMETRY

Elite Symmetry is available as a single-leaf door only. The door features a minimal 48mm non-lockable stile with just 18mm visible on the corridor side when the door is in its closed position. Elite Symmetry door is non-latching/locking and may be fitted with only a pair of stainless steel pull handles.

ELITE AFFINITY

Elite Affinity is our highest performing acoustic glass door. The 97mm internal leading stile; 67mm visible on the corridor side when the door is in its closed position, can accommodate a dead lock, sash lock or latch. This high specification door is the result of extensive product development and testing by Optima and pushes the boundaries of the acoustic performance of glass doors.

The Elite Affinity double-glazed door uses 6mm-toughened glass inside and up to 8.8mm-annealed acoustic laminated glass outside. The Elite Affinity door may incorporate a lock case with either a latch, sash lock or dead lock function and will have stainless steel lever handles or pull handles.

All Optima doors can be supplied with either powder coated or anodised finish to the aluminium framework.

In this EPD, indicators are declared for 1m2 of door based on an Edge Symmetry double-glazed door using 6mm toughened and 8.8mm laminated glass, fitted with handles, a lock, hinges and floor spring. This is representative of all Optima double-glazed doors with 6mm and 8.8mm laminated glass
