ROBIN PAINTE® Fresnel

PAINTE® Fresnel is equipped by CMY colour mixing system, a colour wheel featuring nine dichroic colours, variable CTO and ChromaTint™ green/magenta content control.

Designed for noise-sensitive environments with an appropriate suite of fan controls, PAINTE® Fresnel features a choice of TE™ 310W HP (High Performance) White LED for maximised output of 10.850 lm (integrating sphere) or TE™ 310W HCF (High Colour Fidelity) engines for the best possible colour rendition with an inherent CRI of 96.

The motorised 8.3:1 ratio zoom produces a range of 6°- 50° from its 150mm Fresnel lens.

The PAINTE® Fresnel features beam control for a fixture, including medium and light frosts; RotaScrim™ graduated filter with position control, +/- 180° rotation and edge colour correction; the rapid 4Door™ internal barndoor system for accurate individual leaf control and +/- 90° module rotation to ensure maximum flexibility.

PAINTE® Fresnel is equipped with Cpulse™ flicker-free management for the latest cameras; L3™ Low Light Linearity dimming software for imperceptible fades to black; AirLOC™ (Less Optical Cleaning) technology keeping the optical elements in pristine condition for far longer; EMS™ Electronic Motion Stabiliser technology for enhanced fixture stability."

Parameters:

• Light source: TE™ 310W HP White LED Engine (Patented)
• Light output: 10.850 lm (integrating sphere), 8.670 lm (goniophotometer)
• Zoom range: 6° - 50°
• Effects: 4Door™ Internal barndoor system with +/- 90° rotation, RotaScrim, Colour wheel, 2 frosts
