Pilkington Mirai Insulight™ 6/16/6 Double IGU with Offline Coated Glass
Double Insulating Glass Unit (IGU) (defined in EN 1279-1) are sealed units that comprise two sheets of glass, separated by a spacer, and sealed around the edge with polymeric sealant; a desiccant is contained within the unit to prevent condensation on the inside surfaces.
Pilkington Mirai Insulight™ 6/16/6 Double IGU comprises one pane of 6 mm low carbon float glass, 16 mm argon gas-filled cavity and one pane of 6 mm low carbon offline coated glass.
IGUs are available in a wide range of dimensions and configurations. Different variants provide different technical performance characteristics. Performance characteristics such as light transmittance, thermal transmittance (U value) and acoustic properties can be calculated for any of our products via Pilkington Spectrum: https://spectrum.pilkington.com
Pilkington Mirai Insulight™ IGU is classified CPC 371 under the UN CPC classification system v2.1.
| Registration number | EPD-IES-0024748:001 |
|---|---|
| Status | Valid |
| Initial version date | 2026-01-16 |
| Validity date | 2031-01-16 |
| PCR | 2019:14 Construction products (EN 15804+A2) (version 2.0.1) 2.0.1 |
| c-PCR | 2019:14-c-PCR-009 Being updated - Flat glass products used in buildings and other construction works (EN 17074) (c-PCR to PCR 2019:14) 1.0.0 |
| Standards conformance | ISO 14025:2006, EN 15804:2012+A2:2019/AC:2021 |
| Geographical scope | Global, Europe |
| LCA Practitioner | Chris Foster |
