ST - 340: TECHNICAL MODULE

• System with an interior structure made of galvanized steel.
• The interior structure is covered on both sides with two aluminum covers.
• The covers are secured to the structure with clip-on staples, allowing them to be assembled and disassembled as often as necessary.
• Total system thickness is 100 mm.
• Cradle-to-Cradle certified system at the Bronze level.
• Mechanics and Functionality certified (UNE-EN 41955-2) for maximum use (Use Category 4)

ST-340 is made up of 12 components from three different material groups. Its dimensions are 2750 mm high x 100 mm wide, with a total surface area of 0.275 m2.

Optionally, the TREBE SERIES ST-340 is available in a second version that includes the KUBIK structure.

The KUBIK structure, also referred to as ST-700, is a self-supporting aluminum frame with concealed floor fixation, designed to support the various modular partition systems of the TREBE SERIES.

ST-700 consists of 18 components grouped into 3 different material categories. Its dimensions are 4200 mm in height, 4200 mm in width, and 2600 mm in length, forming a structure capable of supporting a total surface area of 61.32 m² of vertical partition system.

Since ST-700 is an optional component that can be used with all other modules, its environmental impacts will be calculated and considered accordingly. If this structure is included, the weight per square meter of each module increases by 2.12 kg/m².

For the ST-340 SERIES, incorporating the KUBIK structure results in a total weight of 43.15 kg/m².
