EPD-IES-0014422:002

Hot Dip Galvanized steel coils with Magnelis® coating

This Environmental Product Declaration refers to Hot Dip Galvanized steel with Magnelis® Coating. The product is a double-sided hot-dip galvanized carbon steel coated on both sides with a zinc-aluminium-magnesium alloy. This alloy, composed of 93,5% zinc, 3,5% aluminium and 3% magnesium, is applied by means of a continuous hot dip galvanizing process.

Hot Dip Galvanized steel coils with Magnelis® Coating are compliant to EN 10346:2015.

This EPD covers a very wide range of galvanized steel grades:

• Steels for cold forming: DX51D to DX57D,

• Steels for construction: S220GD to S550GD,

• High Strength Low Alloy steels: HX260LAD to HX700LAD,

• Hyper steel grades for Construction: S420GD-Hyper®, S450GD-Hyper®, S550GD-Hyper®, S700GD-Hyper®

in thicknesses from 0,36 to 6mm and coating masses from 70 up to 1000 g/m².

ZM is the symbol used in EN 10346 to refer to Zinc Aluminium Magnesium coatings to which Magnelis® coated steel belongs.

Registration numberEPD-IES-0014422:002
PCR2019:14 Construction products (EN 15804+A2) 1.3.4
StatusValid
Publication date2024-09-02
Valid until2029-09-09
EN 15804 compliantYes
Geographical scopeEurope
