M50 FR

M50 FR is a complete system for curtain walls with high energy efficiency, which offers infinite design possibilities and meets every requirement of contemporary architecture. Its main advantages are the mining design, the high energy efficiency, the increased comfort, security and sound insulation level, and the maximum functionality. Fire resistance of M50FR is achieved by using a special reinforcement profile both in mullion and transom chamber, filled round with cooling material. Intumescent tape is placed in the sides of isolator and glazing holder. Under high temperature, tape is expanding and fills the space in the area of the façade.

Product characteristics

• Basic system width 50mm

• Flat interior appearance thanks to same mullion and transom profile.

• Available mullion and transom depth 105-175 mm.

• Available mullion and transom Moment of Inertia 124-433 cm4.

• max glass dimensions:

        width ≤1452mm

        height ≤ 3204mm

• Compatible with both fireproof glass and aluminium panels.
