Partitions System

ACOSOFT 40 Partition Acosoft 40 Partition is the unique partition for acoustic in sliding solution with dimension 40mm x 25mm. Key features • Special Slim design & Brooklyn option is available. • Suitable for 10mm / 12mm toughened glass thickness & 10.52mm / 11.52mm / 12.52mm / 13.52mm laminated glass thickness • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm • Single glazed systems • Sound insulation capacity of 32 - 34 dB • Ready Available Finish : Silver Anodized & Black Anodized

DOTLINE 25 Dotline 25 series is a demountable office partition system with minimal section visibility & strong acoustic insulation. Key features • Standard track section 25mm x 25mm & 25mm x 40mm • Suitable for 10mm/12mm toughened glass & 10.52mm/ 11.52mm/ 12.52mm/ 13.52mm laminated glass. • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm • Single glazed systems • Sound insulation capacity of 32-34 dB • Ready Available Finish : Silver Anodized & Black Anodized • Brooklyn option available

Duoline 100 Duoline 100 provides excellent acoustic values with optimum transparency. Key features • Standard track section : 100mm x 25mm & 100mm x 50mm • Suitable for 10mm/12mm toughened glass & 10.52mm/11.52mm/12.52mm laminated glass. • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm. • Double glazed systems • Sound insulation capacity of 46-49 dB • Ready Available Finish : Silver Anodized & Black Anodized • Brooklyn option is available.

ECOLINE 100 Ecoline 100 is an elegant glass partition with maximum transparency with key features • Standard track section 100mm x 25mm & 100mm x 50mm. • Suitable for 10mm/12mm toughened glass &10.52mm/ 11.52mm/ 12.52mm/ 13.52mm laminated glass. • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm • Single glazed systems • Sound insulation capacity of 32 - 34 dB (6) Brooklyn option is available • Ready Available Finish : Silver Anodized & Black Anodized

ETALINE 80 Etaline 80 provides excellent acoustic values, incorporating the aesthetic values of a slim drywall partitioning with glass panel construction, slimmest of all available section. Key features • Standard track dimension: 80mm x 18mm & 80mm x 36mm • Suitable for 10mm/12mm toughened glass and 10.52mm/ 11.52mm/ 12.52mm laminated glass • Single door frame sizes to allow for 35mm to 45mm doors • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm • Single glazed system • Sound insulation capacity of 30 dB – 33 dB. • Brooklyn option is available • Readily Available Finish: Silver Anodized & Black Anodized

FINESSE 100 Finesse 100 walls you can easily move beyond permanent drywall solutions & rigid space planning to create flexible & usable workspace solutions which are ready to reconfigure & walls that are easy to relocate for whatever change the future brings. Key features • 100mm thick demountable partition • Maximum height: 3000mm & width of panel not more than 1200mm, for bigger heights, reinforcement of the structure is required • Cove visibility of 25mm on top & bottom • Glass of 5mm/6mm can be used as per requirements • It can be incorporated with wooden panel on both sides & rockwool in between the panel or glass panel on both sides or one side wood one side glass

Kwentha 54 (Double Glaze) Kwentha 54 (Double Glaze) series is a demountable office partition system is pure in design with multiple options. Key features • Standard track section 54mm x 25mm • Suitable for 10mm/12mm toughened glass & 10.52mm/11.52mm/12.52mm laminated glass. • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm. • Double glazed systems • Sound insulation capacity of 46-49 dB • Ready Available Finish: Silver Anodized & Black Anodized • Brooklyn option is available

Kwentha 54 (Offset Glaze) Kwentha 54 (Offset Glaze) series is a demountable office partition system is pure in design with multiple options. Key features • Standard track section 54mm x 25mm • Suitable for 10mm/12mm toughened glass & 10.52mm/ 11.52mm/ 12.52mm/ 13.52mm laminated glass. • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm. • Offset Single glazed systems • Sound insulation capacity of 32-36 dB • Ready Available Finish: Silver Anodized & Black Anodized • Brooklyn option is available

Kwentha 54 (Centre Glaze) Kwentha 54 (Centre Glaze) series is a demountable office partition system is pure in design with multiple options. Key features • Standard track section 54mm x 25mm • Suitable for 10mm/12mm toughened glass & 10.52mm/ 11.52mm/ 12.52mm/ 13.52mm laminated glass. • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm. • Single glazed systems • Sound insulation capacity of 32-36 dB • Single glaze can be easily converted to double glaze or offset glaze without altering base section • Readily Available Finish: Silver Anodized & Black Anodized. • Brooklyn option is available

Magic Wall Magic Wall is a superior double glaze profile system that provide an elegant design solution. Key features: • Standard track section: 60mm x 30mm • Suitable for 10mm/12mm toughened glass & 10.52mm/ 11.52mm/ 12.52mm laminated glass • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm • Double glazed systems • Brooklyn option is available • Sound insulation up to 45dB • Openable stile door & wood door option available

Slimo Wall Slimo Wall is a superior aluminum profile system that provide an elegant design solution. Key features: • Standard track section: 60mm x 30mm • Suitable for 10mm/12mm toughened glass & 10.52mm/ 11.52mm/ 12.52mm/ 13.52mm laminated glass • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm • Single glazed systems • Sliding Door & Swing Door both options available • Sound insulation up to 39dB • Brooklyn option is available

Ultraline 45 Ultraline 45 is a superior lightweight profile system that provide an elegant and cost-effective design solutions. Key features: • Standard track section: 45mm x 25mm • Suitable for 10mm/12mm toughened glass & 10.52mm/ 11.52mm/ 12.52mm/ 13.52mm laminated glass • Partition height can be offered up to 3000mm & width of glass panel not more than 1200mm • Single door frame sizes to allow for flush door 35mm • Single glazed systems • Sound insulation capacity of 32 dB - 34 dB • Readily Available Finish: Silver Anodized & Black Anodized • Brooklyn option available
